UPVC 、 CPVC、 PPH TRUE UNION CHECK VALVE

TRUE UNION CHECK VALVE
Brand: WF
Standard: DIN. ANSI, JIS, CNS
Patent: ZL 2021 2 0999307.2
ZL2021 3 0280116.6
Size: 1/2" (15)-4" (100)
Working pressure: 150PSI
Sealing Gasket: EPDM/VITON
Joint end: SOCKET (ANSI / DIN / JI S/ CNS), THREADED (PT / NPT/ BSPF）BALL/HALF BALL

• Nominal size

• Standard

• Connection

• Material sealing element
